Custom Ozone Water Treatment System Solutions:Large-scale 500g ozone generator is used for wastewater, and large-scale sewage plants reduce COD, deodorize, sterilize and disinfect.
Ozone output: 500G/H
Rated power: 5.5KW
Cooling method: water cooling
Machine weight: customized
Machine size: customized
Ozone concentration: 80-120mg/l
Oxygen flow: 100L/MIN
Can be customized
【Product Structure Features】
Honeycomb ozone tube: a combination of multiple ozone tubes, the internal shape is close to the honeycomb shape, so it is called honeycomb ozone tube, the dielectric material is high-purity dehydroxylated quartz tube, the dehydroxylation is less than 10PPM, the SIO2 content is more than 98%, and the temperature resistance 1600 degrees, withstand voltage 30KV, far higher than the peak high voltage KKV produced by the matching high-frequency high-voltage power supply, and will not be burned by high-voltage breakdown.
Inner electrode: titanium alloy, corrosion resistance is better than 316 stainless steel, in the case of high-voltage and high-frequency continuous discharge, it will not be oxidized, blackened, rusted and deformed after 5 years of use; discharge gap: 0.35MM; sealing material: stainless steel flange, poly Tetrafluoroethylene board plus fluorine rubber ring, anti-oxidation, acid and alkali resistance, service life can reach 8 years.
Do you have a design draft? What is the local normal temperature, humidity, and sea level? The more and more detailed the parameters provided, the more accurate the solution given
What equipment is required in the whole project? What equipment do you already have and what equipment do you need? What are the parameters of the existing equipment?
For the whole project, what kind of effect do you want to achieve? What needs to be corrected of the project? What are the third-party acceptance criteria?
What is your budget for the effect of the project? What equipment do we need to provide?
Inquiry
