Features:
1. Imported customed solenoid valve and Switzerland sieve bed, stable performance;
2. Automatic sieve bed filling equipment, ensure its precision
3. 3L-10L covered product range, specific modification is available on the basis of customers’ requirements;
4. Simple inner structure, ease for assembly and repair,;
5. ISO9001certified product；
6. Health recommend types of compressor to combine with oxygen generator
7. 1 year warranty(under normal operation conditions)
|
Item |
Unit |
OX3L |
OX5L |
OX7L |
OX10L |
|
Oxygen output |
LPM | 3 | 5 | 7 | 10 |
|
Oxygen concentration |
% | 93%±3% | |||
|
Sould level |
Db | less than 50db | |||
|
Power |
W |
≤280 |
≤400W |
≤400W |
≤550W |
|
Pressure(inlet) |
Mpa |
0.18-0.2 |
0.2 | ||
|
Pressure(outlet) |
Mpa | 0.06-0.08 | |||
|
Temperature |
℃ |
indoor temperature | |||
|
Relative humidity |
% |
≤85% | |||
|
Dimension |
cm |
L35*H19*W32 |
L36*W36*H42 | ||
|
Weight |
kg |
17 |
20 | 23 | 25 |
industrial oxygen concentrator， psa oxygen concentrator，oxygen concentrator price
High Efficiency -Specifications
Remarks: Complete Kit including oxygen unit,air compressor,chiller, flowmeter, display board etc.
industrial psa oxygen concentrator price Descriptions:
1. Simple structure, easy to operate, and stable oxygen output.
2. Material: zeolite/alumina; each unit can work independently, and oxygen output can reach to 3-10 LPM or higher.
3. With chiller for cooling air, no need additional refrigerant dryer for reducing cost.
4. Oxygen purity can up to 90+5%. Two oxygen cylinders exchange working, auto drain water, nitrogen and other impurities output.
5. Parts with shipping: chiller, fan and air inlet pipe.
6. Oxygen outlet pressure: 0.06-0.08Mpa.
industrial oxygen concentrator， psa oxygen concentrator，oxygen concentrator price
Do you have a design draft? What is the local normal temperature, humidity, and sea level? The more and more detailed the parameters provided, the more accurate the solution given
What equipment is required in the whole project? What equipment do you already have and what equipment do you need? What are the parameters of the existing equipment?
For the whole project, what kind of effect do you want to achieve? What needs to be corrected of the project? What are the third-party acceptance criteria?
What is your budget for the effect of the project? What equipment do we need to provide?
