UVOZ-3300 high-precision ozone analyze, a variety of measurement range options, high accuracy, stable data, good repeatability, suitable for ozone factories, laboratories, ozone online detection
Range：0-200g/nm, 0-100g/nm, 0-50g/nm 0-100ppm,0-1000ppm
Display interface: 4.3 inch touch screen operation interface
Display unit：g/Nm3 mg/NL %WT ppm mg/Nm3
Sampling Method: active pressure sampling/pumping sampling
Content Interface: ozone concentration/ temperature compensation
pressure compensation/Mass flow & output display
Light Source Life：About 10000 hours
Display Interface:4.3 inch touch screen operation interface
Auxiliary Function: concentration&temperature & pressure compensation
Sampling Flow：0.5L±0.2L/min
Input Pressure：<0.1MPa
Concentration Error :< 0.3％FS
Line Deviation :< 0.3％FS
Zero Drifting：<±0.3%.FS
Response Time:the signal is 0.03S, showing is 0.3S.
Ambient Temperature :-20～50℃；
Sampling Caliber of Series Connection:
Bypass samplingΦ6 (6*4mm fast twisting interface)
Communication Mode：RS-485
Output Mode：4-20mA
Relay Signal: High alarm, Low alarm
Power Supply: AC 110-220V；
Dimension：230mm(height）×330mm(width)×150mm(depth)
Standard configuration: Antiseptic flowmeter filter
Ozone tail gas destroyer sampling pump
Product design principle
Based on Lambert Bill's law, the analyzer of UVOZ-1200 by measuring the change of the
intensity of the light signal before and after the UV absorption to calculate the current ozone concentration. The equipment
adopts the advanced dual UV light source system with the intelligent management system of the lamp tube and separated photocell
technology that enables the analyzer has the characteristics of no leakage, anti-high pressure, anti sampling gas impact.
