Large ozone generators are used for water treatment, decolorization, sterilization and purification. We specialize in the production of 100g to 5000g swimming pool ozone water treatment system, with a service life of more than 5 years. We can design and customize ozone generators according to budget.
Ozone output: 100-5000G/H
Rated power: 1KW-5KW
Cooling method: water cooling
Machine weight: customized
Machine size: customized
Ozone concentration: 80-120mg/l
Oxygen flow: 200L/MIN
1-5KG ozone water treatment system Can be customized
【swimming pool ozone water treatment system】
The commonly used sterilization method in water treatment now is ozone. Ozone is obtained by the ionization of oxygen through high-voltage discharge. It has a high killing rate and fast speed for microorganisms such as viruses and bacteria, and can completely remove pollutants such as organic compounds without secondary pollution.
swimming pool ozone water treatment system
Ozone water treatment system Product Introduction
High-voltage transformer
Features of high-voltage transformer:
1) It uses high-quality A-grade magnetic core, which has high magnetic flux and low heat generation, thereby reducing the power consumption of the whole machine.
2) The temperature control system realizes alarm, tripping and other functions according to the measured temperature value, and adopts magnetic core protective paint to paint and encapsulate for corrosion protection.
3) Both high and low voltage windings use H-grade insulation materials, and the coils are wound with high-quality oxygen-free copper\double-glass copper wires. It adopts vacuum varnishing and high-temperature curing process, with high insulation level and strong overload capacity.
High-efficiency discharge tube
Adopts a micro-gap dielectric barrier discharge design with multiple independent intellectual property rights and patented technologies - high-temperature resistant HQG non-glass structure discharge unit. This structure is extremely stable and has a long service life. It has the characteristics of high discharge efficiency and is not easily damaged by backwater.
The operating efficiency is greatly improved, and the safety and reliability of the continuous operation of the system are increased. The technical parameters of the ozone system, such as the maximum ozone concentration of 270mg/l, the rated ozone concentration of 150mg/l, and the unit ozone power consumption of 8.5kwh, have reached the advanced level of similar products.（swimming pool ozone water treatment system）
5kG swimming pool ozone water treatment system
swimming pool ozone water treatment system
Four factors that need to be controlled in ozone sterilization operation:
1. Flow rate, i.e. the amount of ozone and water flow per unit time;
2. The contact area between ozone and water;
3. The flow rate of water and ozone per unit time;
4. The contact time between ozone and water.
ozone water treatment system Features:
1. High Quality Honeycomb quartz tube reaction chamber
2. Cooling way : air + water cooling
3. Feed outside oxygen machine or air compressor
4. High Ozone concentration 80~120g/m3
5. The system is compact and easy to install
When ozone is used to disinfect swimming pool water, the amount of ozone used is determined by the water flow rate per hour when the entire pool water circulates once. Usually, 1-2g of ozone is used for 1m3/h of water, and then a small amount of disinfectant is added. When 1m3/h of swimming pool water uses ≥4g of ozone, the pool water no longer needs to be added with disinfectant, and the pool water will become clear and blue.
Do you have a design draft? What is the local normal temperature, humidity, and sea level? The more and more detailed the parameters provided, the more accurate the solution given
What equipment is required in the whole project? What equipment do you already have and what equipment do you need? What are the parameters of the existing equipment?
For the whole project, what kind of effect do you want to achieve? What needs to be corrected of the project? What are the third-party acceptance criteria?
What is your budget for the effect of the project? What equipment do we need to provide?
Anna Alfano
Dec 09, 2024
We had a leak in our sunroof and rain came in and mold smell came afterwards. I tried many other things to get rid of the smell as we knew where the water fell into the back seat and on the rear floor. I sprayed the seat and the floor with 3% hydrogen peroxide which did not fully get rid of this mold. The ozone treatments with this device helped me destroy the remainder as the gas could penetrate crevices where the peroxide spray couldn't reach.
JA Steel
Oct 30, 2024
ozone is a little heavy, takes a TON on electricity but it is way powerful it will replace ALL of the breathable air in a room you have to shut the doors and get out of there the ozone looks like light smoke. get all pets and people out of the room. Has a timer on it you calibrate it to the square footage but it will literally kill all insects, sterilize the room and STRIP any and all smells from ANY and all surfaces in the room. It will remove cat pee smell on the molecular level- also diesel smell. it also works on dog pee smell and chicken coups. it also kills flies and repels most insects. Also kills rats by suffocation. ask me how I know.
Kelvin M
May 30, 2024
I was skeptical about this, but it definitely work. But use wisely. My house is 1300sqft. I smoke and have a dog, I live in Missouri with very high humidity and I had a musky crawl space(just to give you what I was experiencing).
The process I used was I put the generator on a chair elevated in front on my basement door on the 1st level(1 level house with finished basement). Set it for 2 hr with the fan on my a/c unit running. Left the house with my dog. After about 1 hour I switched the a/c unit to air conditioner (I have a smart thermostat to controll from my phone). For the last hour I ran the original air conditioner. Gave that an extra hour to cycle. Came home and it was such a fresh smell, but definitely can tell the machine worked. It is a hint of smell of the ozone but not bad. To make sure it was safe. I opened a few windows and again set the thermostat on only fan for 1 hour to make sure it was safe(dog outside). In total it was 4 hours process. I really feel that I could have just done 30 mins - 1 hour of the generator running but I wanted to be safe. I definitely recommend this and do some short research on YouTube. Buy this for smelly homes. Ask me about the process and I'll tell you if my comment was not clear.
Sam
Jan 1, 2024
I bought a pickup truck and, although everything else about it is what I wanted, there was a strong smell of cigarette smoke in the cabin, despite a thorough cleaning by vacuuming and wiping down all hard surfaces.
I saw a number of recommendations and reviews for ozone generators as being the solution but I admit to being very skeptical. I bought this ozone unit and set it up in the truck with a slightly lowered rear passenger side window and the AC on recirculate. I ran the unit for half an hour. Finally, I then ventilated it with all windows open and a table fan running full and oscillating inside on the console between the front seats.
The result was nothing short of astounding! The smell was almost completely eliminated. I would estimate it is 85% gone. I could still smell a trace and will run another pass with the ozone generator in the next few days when I get a chance to replace the cabin air filter. I expect it to be even better after that run.
Stavros
Nov 12, 2021
Would you like to know how performance monitoring of your water treatment system can deliver valuable insights that let you reduce costs? Also how to make a design your water treatment system?
Listen to these guys discuss how you can do this – they will make the perfect equipment for you! They’ll tell you how getting to know the costs involved in your water treatment system can help you react to and even avoid the activities that cost you extra.
Adrian
Dec 12, 2019
Ozone treatment provides a treatment that is both faster and less corrosive than traditional chlorine treatment. And it is a green strong oxidant. After it finishes its work, it can be oxidized and reduced to oxygen, which is very friendly to the environment. So we use the ozone instead of the chlorine for the wastewater treatment.
JOE
Mar 26, 2015
The purchase of the ozone air purifier coincided with the Chinese New Year, so the slight delay in shipping is understandable. After sending from China to Russia, Voronezh took only six days. There was no damage to the packaging, the courier delivered the package. The ozone air purifies itself in perfect condition. This is a rather complicated device, so I can only judge by the first impression - while everything is working. The seller entered dialogues promptly and answered all questions. I am very pleased with almost everything - the fast delivery, the ozone air purification himself, the friendliness and competence of the managers.-
Baron
Jun 05, 2012
Proper water treatment is essential for all water-containing systems, including commercial sludge treatment. Without proper water treatment, sludge treatment systems experience significant issues with corrosion, scale, bacteria, and sludge. Not only does water treatment enhance the longevity of equipment, but it increases the energy efficiency of the system. The Health Sci-Tech offers us a nice system, it could help us a lot! We loved it, we had nice contact with each other.
